Quick Details:
Model: Counterbalanced electric warehouse forklift trucks CPD15R
Capacity: 1500kg
Lift height: 2500-5600mm
Fork dimensions: 35/100/950(1070)mm
Aisle width for pallets 1000*1200 lengthways: 2990mm
Aisle width for pallets 800*1200 crossways: 3120mm
Turning radius: 1600mm
Travel speed, load/unload: 6.8/7km/h
Lifting speed, load/unload: 0.12/0.19m/s
Lowering speed, load/unload: 0.42/0.41m/s
Battery: 24V320Ah
Service weight: 2030kg
Advantages:
Option:
| SPECIFICATIONS OF COUNTERBALANCED WAREHOUSE FORLIFT TRUCKS | ||
| Model | CPD15R | |
| Load capacity | kg | 1500 |
| Load center distance | mm | 500 |
| Load distance | mm | 130 |
| Tyre size, front | mm | 250*70 |
| Tyre size, rear | mm | 200*100 |
| Additional wheels (dimensions) | mm | 150*60 |
| Fork, tilt forward/backward | ° | 3/6 |
| Height, mast lowered | mm | 1735/1985/2235/1895/2085/2235/2435 |
| Free lift (option) | mm | 0/0/0/1400/1500/1670/1870 |
| Max. lifting height | mm | 2500/3000/3500/4000/4500/5000/5600 |
| Height, mast extended | mm | 3500/4000/4500/5000/5500/6000/6600 |
| Height of tiller in drive position min./max. | mm | 1160/1460 |
| Overall length | mm | 2660 |
| Length to face of forks | mm | 1700 |
| Overall width | mm | 990 |
| Fork dimensions | mm | 35/100/950(1070) |
| Width overall forks | mm | 220-680 |
| Aisle width for pallets 800*1200 lengthways | mm | 3120 |
| Turning radius | mm | 1600 |
| Travel speed, laden/unladen | km/h | 6.8/7 |
| Lift speed, laden/unladen | m/s | 0.12/0.19 |
| Lowering speed, laden/unladen | m/s | 0.42/0.41 |
| Battery | V/Ah | 24/320 |
| Service weight | kg | 2030 |
